ADG706BRUZ-REEL7 Electronic Components IC Chip CMOS Low Voltage 16-Channel Multiplexers​

Brand Name : ADI / MAXIM

Model Number : ADG706BRUZ-REEL7

Place of Origin : original

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 999999

Delivery Time : 1-3 days

Packaging Details : standard

Multiplexer/Demultiplexer Circuit : 16:1

On-State Resistance (Max) : 4.5Ohm

Channel-to-Channel Matching (ΔRon) : -

Voltage - Supply, Single (V+) : 1.8V ~ 5.5V

Voltage - Supply, Dual (V±) : ±2.5V

Switch Time (Ton, Toff) (Max) : 32ns, 16ns (Typ)

PN : ADG706BRUZ-REEL7

Contact Now

ADG706BRUZ-REEL7  Electronic Components IC Chip CMOS
Low-Voltage   8- 16-Channel Multiplexers Package 28-TSSOP





Product Status
Active
Switch Circuit
-
Multiplexer/Demultiplexer Circuit
16:1
Number of Circuits
1
On-State Resistance (Max)
4.5Ohm
Channel-to-Channel Matching (ΔRon)
-
Voltage - Supply, Single (V+)
1.8V ~ 5.5V
Voltage - Supply, Dual (V±)
±2.5V
Switch Time (Ton, Toff) (Max)
32ns, 16ns (Typ)
-3db Bandwidth
25MHz
Charge Injection
8pC
Channel Capacitance (CS(off), CD(off))
13pF, 180pF
Current - Leakage (IS(off)) (Max)
100pA
Crosstalk
-80dB @ 1MHz
Operating Temperature
-40°C ~ 85°C (TA)
Mounting Type
Surface Mount
Package / Case
28-TSSOP (0.173", 4.40mm Width)
Supplier Device Package
28-TSSOP


FEATURES
+1.8 V to +5.5 V Single Supply
2.5 V Dual Supply
2.5 ON Resistance
0.5 ON Resistance Flatness
100 pA Leakage Currents
40 ns Switching Times
Single 16-to-1 Multiplexer ADG706
Differential 8-to-1 Multiplexer ADG707
28-Lead TSSOP Package
Low-Power Consumption
TTL/CMOS-Compatible Inputs
APPLICATIONS
Data Acquisition Systems
Communication Systems
Relay Replacement
Audio and Video Switching
Battery-Powered Systems
